Vuzix M400™ Smart Glasses

Vuzix M400™ Smart Glasses - Video 8
Technical Specifications

  • Display resolution: nHD color display
  • Display type: OLED
  • Aspect ratio: 16:9

  • Field of view (diagonal):

    16.8°, equivalent to a 5 in. mobile device screen seen at 17 inches

  • Brightness: > 2000 nits
  • Contrast: > 10,000:1
  • 24-bit color with true black
  • Supports left or right eye use

  • On-board battery to enable hot swapping for zero down-time

  • 4 control buttons
  • Voice control
  • 2 axis touchpad with multi-finger support

  • USB 3.1 Gen 2 on USB Type-C
  • Wi-Fi 2.4/5Ghz 802.11 a/b/g/n/ac
  • Bluetooth 5.0 BR/EDR/LE

  • 8 Core 2.52Ghz Qualcomm XR1
  • 6GB LPDDR4 RAM
  • 64GB internal flash memory
  • Upgradeable to Android 13 OS
  • OS and apps OTA upgradeable
  • MDM available from multiple partners

  • Integrated speaker (up to 97db output)
  • Triple noise-canceling microphones
  • Bluetooth audio: HSP/A2DP

  • Up to 13-megapixel stills
  • Streaming video at 1080p, 60fps
  • Improved auto-focus (PDAF)
  • LED flash/scene illumination
  • Barcode scanning

  • 3-degree of freedom head tracking
  • 3 axis gyro
  • 3 axis accelerometer
  • 3 axis mag/integrated compass

  • Operating temperature -20ºC to 50ºC
  • Operating humidity 0-95% RH
  • Storage temperature -30-70ºC per MIL-STD-810H
  • Storage humidity 0-95% RH
  • IP67 rated protection against water and dust

  • 3200mAh Xtreme Weather Power Bank
  • IP67 rated protection against water and dust
  • Rated -20ºC to 45ºC (-4°F to 113°F)

  • GPS/GLONASS

  • Vuzix All-Day Comfort Headband with Universal Rail

  • Drop safe to 2 meters
  • IEC6060-1-1-2:2014 Medical Device Safety and Performance certified
  • ISO 14644-1 Class 2 Clean Room rating
Overview

Built for demanding environments, the M400 Xtreme Kit is ideal for outdoor operations and cold storage settings. It includes the rugged 3200 mAh Xtreme Weather Battery (IP67 rated, temperature tested), offering extended performance in extreme conditions. Paired with a comfortable headband and essential accessories, this kit is tailored for remote fieldwork and full-day industrial tasks.

Applicable Solutions

Designed for rugged environments and extended outdoor use, Vuzix M400™ Smart Glasses provide reliable, hands-free access to digital content even in extreme conditions. Combined with custom AR software from Program-Ace, they support a wide range of mission-critical operations across fieldwork and industrial settings:

  • AR field service & maintenance
  • Remote expert collaboration
  • AR training & onboarding
  • Warehouse navigation & smart inventory
  • Quality inspection & visual validation
  • Hands-free healthcare support
  • AR demos & sales presentations

Included in the Kit:

  • M400 Smart Glasses (IP67 certified; operational from -20°C/-4°F to 45°C/113°F)
  • 3200 mAh Xtreme Weather Battery (IP67 certified; same temperature range)
  • All-Day Comfort Headband
  • M400 Power Cable
  • USB Charging Cable
  • Protective Carrying Case
  • Quick Start Guide & User Manual
  • Mounting Guide
  • One-Year Manufacturer Warranty
Languages:

English, Arabic, Bulgarian, Cantonese – Traditional Script, Czech, Danish, Dutch, Finnish, French, German, Greek, Hebrew, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Mandarin – Simplified Script, Mandarin – Traditional Script, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish

Tags:

AR, AR Glasses, Smart Glasses

Manufacturer:

Vuzix
